MOON Ace Streaming Amplifier
One of the best One Box System's on the market, With the same Integrated amplifier from the award winning Moon 240i Integrated Amplifier but also includes the addition of a Streaming DAC, using Simaudio’s MiND2 (MOON intelligent Network Device) module, allowing you to access your digital music library and streaming services, simply hook up a pair of speakers, connect to the internet and you are ready for music, lots of music.
Features
-
3 line-level inputs including a front-mounted 1/8” mini-jack for personal media players.
-
Headphone output on 1/4” jack located on the front panel.
-
Seamless integration with our MiND app.
-
8 digital inputs include USB (hi-res audio), SPDIF (2), Optical (2),Qualcomm aptX audio for Bluetooth®, WiFi and Ethernet.
-
OLED type screen which provides more detailed information.
-
Simple MiND setup via on-board software menu.
-
Moving magnet phono preamplifier input.
-
Analog inputs are configurable to “pass-through” mode, which bypasses the gain stage to accommodate components like a home-theater processor, whose own volume control is used.
For MOON ACE equipped with MiND 2:
-
Roon Ready device
-
Tidal Masters, Deezer Hi-Fi and Qobuz Sublime+ Music Services
-
MQA decoding
-
Multi-room synchronized playback
The ACE is both intuitive and easy to use. Featuring all new advanced setup software, this is the most configurable and customizable MOON component ever offered. Bridging digital and analog audio at a price-to-performance ratio that is impossible to beat, the ACE includes a high resolution DAC with DSD decoding up to DSD256 and 32-bit/384kHz PCM. At the other end of the audio spectrum, a moving magnet phono preamplifier rounds out this complete package.
The finest sounding and most complete “all-in-one” available, the ACE can do virtually anything expected of a high-performance audio component of this nature. Accentuated by Simaudio’s world renowned MOON sonic signature – visceral tight bass, transparent midrange, precise natural highs – along with lifelike sound, plus countless features, the ACE will be the “heart and soul” of all your musical indulgences.
Specifications
| Output Power At 8Ω: | 50 W per channel |
| Input Sensitivity: | 370 mV – 3.0 V RMS |
| Input Impedance: | 22.1 kΩ |
| Gain: | 37 dB |
| Signal-to-noise Ratio: | 100 dB at full power |
| Frequency Response (Full Range): | 10 Hz – 80 kHz +0/–3 dB |
| Crosstalk: | -100 dB |
| THD (20 Hz – 20 kHz At 1 W / 50 W): | 0.02% / 0.02% |
| Intermodulation Distortion: | 0.005% |
| PCM Bit-depth Range / Sampling Rates: | 16 – 32 bits / 44.1 – 384 kHz |
| DSD Sample Rates: | DSD64, DSD128 and DSD256 |
| Shipping Weight: | 24 lb / 11 kg |
| Dimensions (Width x Height x Depth): | 16.9 x 3.5 x 14.4 in42.9 x 8.9 x 36.6 cm |
Original: $3,924.36
-70%$3,924.36
$1,177.31Product Information
