MOON 340i X Integrated Amplifier

Loaded with numerous convenient features and unbeatable sonic performance, the 340i X provides for unprecedented flexibility. In addition, the 340i X flexibility is enhanced by a host of options which can be included at the time of purchase or added later on.

Features

• 6 (six) line-level inputs including a front-mounted 1/8” mini-jack for personal media players.

• 1 (one) pair of balanced input (XLR).

• Headphone output on 1/4” jack located on the front panel.

• A massive oversized power supply using a custom toroidal transformer design.

• “Class A” output to 5 watts for greater efficiency.

• One audio input which functions as a “pass-through”, bypassing the gain stage to accommodate components like a home-theater processor, whose own volume control is used instead.

• Precision matched proprietary MOON Bipolar output transistors for improved bass response and accurate sonic reproduction.

Combining high power, sonic finesse and superb flexibility, the 340i X will seduce you with its musical authority, as well as its rich, engaging and lifelike sound quality.

A high-performance and very versatile DAC is offered for connectivity to your latest devices such as a computer, DVD/Blu-Ray player or an iPod docking station. If you have a love for spinning your cherished collection of vinyl records, a fully-configurable MC/MM phono stage is also available.

Winner of 12 awards, the 340i X can easily be the centre piece of your music and entertainment system.

Featuring an options package, unheralded in the world of high-performance audio, which includes (1) an internal digital-to-analog converter (USB-2, S/PDIF & TosLink digital inputs), (2) an internal RIAA phono preamplifier (MM & MC) and (3) a balanced line-level input. All 3 of these options are available in any combination, either at the time of purchase or as a future upgrade.

The standard 340i X is £4100, with D3 and P options installed at factory (340i D3PX).

The MOON 340i X combines almost 30 years of experience in the design and manufacturing of award winning products with numerous unique technologies found in many of Simaudio’s other components. The 340i X will be the heart and soul of your home-entertainment system for many many years … call it the birth of a legend.

Specifications

Output Power At 8 Ω:	100 W per channel
Output Power At 4 Ω:	200 W per channel
Input Sensitivity:	370 mV – 3.0 V RMS
Input Impedance:	11,000 Ω
Gain:	37 dB
Signal-To-Noise Ratio:	110 dB at full power
Frequency Response (Full Range):	2 Hz – 90 kHz (+0 / –3 dB)
Crosstalk:	–88 dB
Total Harmonic Distortion (20 Hz – 20 kHz At 1 W):	0.015%
Total Harmonic Distortion (20 Hz – 20 kHz At 100 W):	0.05%
Intermodulation Distortion:	0.03%
Optional Digital Inputs:	S/PDIF, USB, Optical
Maximum PCM Resolution:	32-bit / 384 kHz
DSD Sample Rates:	DSD64, DSD128, DSD256
Shipping Weight:	28 lb / 13 kg
Dimensions (W × H × D):	16.9 × 3.5 × 14.8 in 42.9 × 8.9 × 37.6 cm
